MGI-250 · PULSE METER ±0.5% · 1" or 1 1/2"

Liquids: Diesel Diesel  Lubricant Lubricant
MGI-250 · Pulse meter

Pulse meter for its in-line assembly, making easier the exact information of the fluid management and control systems.



Technical data:

  • Flow (approx.):
    • 10-250 l/min (diesel)
    • 10-150 l/min (lubricant
  • Voltage: 100 VDC
  • Max. power: 8 W
  • Maximum current: 100 mA
  • Accuracy: ±0.5%
  • Maximum pressure: 45 bar
  • Min./max. temperature: -10ºC / +50ºC
  • Two channels: 11 pulses per litre and channel
  • Inlet / outlet connection: F1" or 1 1/2" (flange)
  • Housing and cover: Aluminium
Size and weight (approx.):
MGI-250 1"
  • Size: 159x100x141mm (lenght x width x height)
  • Weight: 2.3Kg
  • MGI-250 1 1/2"
    • Size: 183x100x141mm (lenght x width x height)
    • Weight: 2.5Kg
MGI-250 · PULSE METER
